Deltoid Catacaustic


DeltoidCatacaustic

Amazingly, the catacaustic of the deltoid when the rays are parallel in any direction is an astroid. In particular, for a deltoid with parametric equations

x=2cost+cos(2t)
(1)
y=2sint-sin(2t),
(2)

the catacaustic for rays incident from an angle theta is the offset deltoid given by

x=3cost+cos(3t+2theta)-cos(2theta)
(3)
y=3sint+sin(3t+2theta)+sin(2theta).
(4)
Animation of the catacautic of a deltoid as the angle of incident rays is changed

For incident rays making an angle theta with respect to the x-axis, the resulting astroid is titled at an angle theta/2 and has center offset so that the astroid rolls along the deltoid, completing half a turn as the incident rays rotate around a full turn. This therefore provides a construction for an astroid with a deltoid rotor.


See also

Astroid, Catacaustic, Deltoid, Rotor
